AKM2G Instructions | 7 Technical Data
7.7.1.1 AKM2G-71 Derates for Different Options
Note: Derate information is for general estimation only. Use the online Performance Curve Generator located at
the most accurate information for your motor, or refer to Kollmorgen's Motioneering Software Tool available for download at
www.kollmorgen.com/en-us/service-and-support/technical/motioneering/motioneering/.
De-rates are referenced to the Max Continuous Torque ΔT wdg. = 100°C
Options - No Brake
Resolver
Resolver/Seal
SFD
SFD/Seal
DSL
DSL/Seal
EnDat2.2
EnDat2.2/Seal
De-rates are referenced to the Max Continuous Torque ΔT wdg. = 100°C
Options - Brake
Resolver
Resolver/Seal
SFD
SFD/Seal
DSL
DSL/Seal
EnDat2.2
EnDat2.2/Seal
Note: For EnDat feedback motors acceleration of the motor is limited to ≤1*10
connected servo drive may further limit this value.
