To ensure the system functions correctly it is necessary that between the MASTER Wi-Fi
OS and the safety devices there are no obstacles such as reinforced cement walls, iron
surfaces, etc. that could obstruct the radio communications and consequently reduce the
battery life of the safety devices.
NOVA Wi-Fi AND VERTIGO Wi-Fi PHOTOCELLS ALARM SIGNAL CHECK
Check that by taking the battery out of the photocell receiver with micro-switch, for example
3 in the ON on position, and commanding the door to open, the dual-color LED3 on the
MASTER Wi-Fi OS alternates green and red , while LEDs DL1, DL2 and DL3 turn off, and
that the buzzer emits an alternating sound for 1 minute.
Repeat the check for any other photocell receivers installed.
Note: if when removing the battery and commanding the door to open the buzzer on the
MASTER Wi-Fi OS does not sound, micro-switch 3 on the MASTER Wi-Fi OS is in the OFF
position (go-ahead not enabled). Turn it to ON.
TOUCH Wi-Fi STRIP ALARM SIGNAL CHECK
Check that by taking the battery out of the transmitter with micro-switch, for example DIP3
in the ON position, the dual-color LED EDGE PHOT 3 on the MASTER Wi-Fi lights flashing
red while LED DL2 turns off, and that the buzzer emits every 3 seconds sound for 1 minute.
Repeat the check for any other strips installed.
Note: if the battery is removed and the buzzer on the MASTER Wi-Fi OS does not sound,
micro-switch 3 on the MASTER Wi-Fi OS is in the OFF position (go-ahead not enabled).
Turn it to ON.
WARNING (replace the batteries)
The WARNING tells the user of the immediate need to replace the batteries.
When battery power reaches 2,3V for NOVA Wi-Fi/VERTIGO Wi-Fi and 3V for TOUCH Wi-Fi,
these devices signal the MASTER Wi-Fi OS via radio of the low battery status and activate
the BUZZER of the MASTER Wi-Fi OS with a sound every 3 seconds for 1 minute.
The warning is renewed for 1 minute if a command is given to the door.
The dual-color LED on the MASTER Wi-Fi OS corresponding to the photocell or the strip with
the low batteries emits a constant red light.
The SPARK Wi-Fi blinker (if available) indicates the warning by emitting 2 consecutive flashes
followed by a pause for 3 seconds for the duration of the opening or closing of the door.
The system is still operational during these signals, but it is advantageous to replace the
batteries as soon as possible in order to avoid a full stop of the door operation which happens
when the batteries reach 2,0 V for NOVA Wi-Fi/VERTIGO Wi-Fi and 2,7 V for TOUCH Wi-Fi.
ALARM (batteries completely exhausted or not working)
The alarm activates when the batteries are completely exhausted (2V for NOVA Wi-Fi/
VERTIGO Wi-Fi and 2,7V for TOUCH Wi-Fi) or when they stop working.
On MASTER Wi-Fi OS the LEDs DL1, DL2 and DL3 turn off MASTER Wi-Fi OS blocks the
automation.
On MASTER Wi-Fi the dual-color LED corresponding to the photocell or the strip with the
low or non-functioning batteries flashes red. The BUZZER emits a sound every 3 seconds
for 1 minute, while the SPARK Wi-Fi blinker (if available) signals the alarm status by emitting
emitting 2 consecutive flashes followed by a pause for 3 seconds, notifying the user that the
batteries must be replaced or repaired.
The alarm is renewed for 1 minute if a command is given to the door.
REPLACING THE BATTERIES
The lifespan of the 1.5 V AA batteries used in the safety devices is about 3 years.
In case it is required to replace the batteries, it will not be necessary to re-program the
photocells, nor any other RIB Wi-Fi accesories.
- Identify the safety device with the exhausted batteries by checking the diagnostic of the
LED EDGE PHOT on the MASTER Wi-Fi OS.
- Using the number on the side of the dual-color LED EDGE PHOT which is flashing red or
that emits a constant red light identify the number of the safety device with the exhausted
batteries.
- Find the NOVA Wi-Fi or TOUCH Wi-Fi device with the adhesive strip bearing the
identification number corresponding to the number of the dual-color LED which is in alarm
status on the MASTER Wi-Fi OS.
- Replace the batteries, checking that the polarity is correct.
- Push button PROG TX on the NOVA Wi-Fi or TOUCH Wi-Fi to restart the MASTER Wi-Fi OS.
- The buzzer on the strip of the MASTER Wi-Fi OS will turn off and the LEDs DL1-DL2-DL3
(if in alarm status) will come on. The dual-color LED corresponding to the safety device
with the replaced batteries will turn off.
The automation is now ready for safe operation.
ATTENTION: Please remember that batteries must be disposed of properly according to
current standards. In case of disposal of the safety devices please remember to remove the
AA batteries and dispose of them properly
TOTAL REMOVAL PROCEDURE FOR MEMORIZED SAFETY DEVICES
To perform a total removal of the safety devices (NOVA Wi-Fi and TOUCH Wi-FI)
recorded in the MASTER Wi-Fi OS memory just push and hold the button PROG. RX for 10
seconds.
After 10 seconds all of the dual-color LEDs (from EDGE PHOT 1 to EDGE PHOT 6) will flash
alternately 6 times, indicating successful removal.
Afterwards the dual-color LED EDGE PHOT and LEDs DL1, DL2 and DL3 will turn off.
ATTENTION: WITH LED DL1, DL2 AND DL3 OFF AUTOMATION DOES NOT WORK.
REMOVAL PROCEDURE FOR A SINGLE SAFETY DEVICE (PHOTOCELL OR STRIP)
In order to remove a single memorized safety device on the MASTER Wi-Fi OS, use the
following procedure:
- Push the button PROG. RX one or more times to select the dual-color LED EDGE PHOT
which begins flashing green, corresponding to the safety device to be eliminated.
- After selecting the safety device, push and hold the button PROG. RX for 10 seconds.
- After 10 seconds the dual-color LED EDGE PHOT flashes alternately red and green 6 times,
indicating successful removal.
ATTENTION: Place the micro-switch corresponding to the eliminated safety device in
the OFF position, then scan the dual-color LED pushing the button PROG. RX 6 times.
IMPORTANT: Remove the batteries from the eliminated safety device.
H -
PROGRAMMING THE SPARK Wi-Fi BLINKER
- Push and hold the button PROG. RX on the MASTER Wi-Fi OS for at least 3 seconds.
- After releasing the button PROG. RX the dual-color LED DL7 will begin flashing red for
10 seconds.
- Push the button S4 PROG. TX on the SPARK Wi-Fi blinker to send a radio signal to the
MASTER Wi-Fi OS.
- Successful memorization is indicated by a sound from the buzzer and the red dual-color
LED DL7 on the MASTER Wi-Fi OS turning green, while the red LED DL7 on the SPARK
Wi-Fi card flashes 3 times.
- Allow 10 seconds to pass to conclude programming, or push button PROG. RX on the
MASTER Wi-Fi OS for a moment.
- Replace the casing.
- Mount the diffuser and attach it with the screws provided.
More than one blinker can be memorized by the MASTER Wi-Fi OS.
Each SPARK Wi-Fi blinker receives during the memorization one single identic code from the
MASTER Wi-Fi OS to which it is paired up.
When the MASTER Wi-Fi OS is activated by a command, all SPARK Wi-Fi blinkers memorized
in it will start blinking simoultanesly.
SYSTEM CHECK
Give a command to the door and check that the SPARK Wi-Fi blinker flashes correctly.

TECHNICAL SPECIFICATIONS

- POWER
- APPLICABLE TENSION ON CONTACT J4
- APPLICABLE TENSION ON CONTACT J2
- ABSORPTION AT REST
- MAXIMUM ABSORPTION
- WORKING TEMPERATURE
- SIZE
- WEIGHT
SAFETY DEVICES AND SIGNALING RADIO FREQUENCY SIGNAL TECHNICAL
INFORMATION
- FREQUENCY
- SENSITIVITY
- EMITTING POWER
- MODULATION TYPE
- RANGE
23
12/24 Vac/dc
120/220/230V 50/60Hz
12/24V ac/dc
40 mA
100 mA
-20°C ÷ +60°C
125x55x28 mm
0,090 kg
868,3 MHz
-108 dBm
<25 mW
FSK
20 m in open spaces
G
B
