Figure 7. Drive carrier with 3.5-inch SATA disk drive and adapter
Disk Drive
mounting screw
Figure 8. Drive carrier with 3.5-inch SAS disk drive
Disk Drive
mounting screw
Disk Drive
mounting screw
Disk Drive
mounting screw
10
Task 3: Installing Disk Drives
SATA Disk Drive
AAMUX adapter
adapter
mounting
screw
SAS Disk Drive
adapter
mounting
screw
