Technische Daten
3x525-690 V
Leistung Max. Bussmann
[kW] Vorsicher E52273
ung [A] RK1/JDDZ
11-15 30 KTS-R-30
22 45 KTS-R-45
30 60 KTS-R-60
37 80 KTS-R-80
45 90 KTS-R-90
55 100 KTS-R-100
75 125 KTS-R-125
90 150 KTS-R-150
Table 8.24 3x525-690 V, Gehäusetypen B und C
MG20MA03
Produkthandbuch
Empfohlene max. Sicherung
Bussmann Bussmann
E4273 E4273 E180276
J/JDDZ T/JDDZ RK1/JDDZ
JKS-30 JKJS-30 5017906-030
JKS-45 JJS-45 5014006-050
JKS-60 JJS-60 5014006-063
JKS-80 JJS-80 5014006-080
JKS-90 JJS-90 5014006-100
JKS-100 JJS-100 5014006-100
JKS-125 JJS-125 2028220-125
JKS-150 JJS-150 2028220-150
Danfoss A/S © Ver. 2014-05-14 All rights reserved.
SIBA LittelFuse
E81895
RK1/JDDZ E163267/E2137
KLS-R-030
KLS-R-045
KLS-R-060
KLS-R-075
KLS-R-090
KLS-R-100
KLS-150
KLS-175
Ferraz- Ferraz-
Shawmut Shawmut
E2137
RK1/JDDZ J/HSJ
A6K-30-R HST-30
A6K-45-R HST-45
A6K-60-R HST-60
A6K-80-R HST-80
A6K-90-R HST-90
A6K-100-R HST-100
A6K-125-R HST-125
A6K-150-R HST-150
