When using supplied power with the engine on:
• The back-lighting is on permanently when the engine is running.
Using only the internal battery:
• With the LO symbol, the backlighting will not switch on. The symbol appears
when the battery voltage is lower than 2.45V.
Reset Button:
Using the Reset button, located on the back of the instrument, all travel data will be
deleted, including date and time.
Internal battery:
The instrument houses a 3.0V internal button cell battery (CR2032). The instrument
can only work with this battery. The
running low. To change the battery, unscrew the cap located on the back of the
instrument using a coin.
Once the battery has been changed, make sure that the positive side is facing
outwards.
REPLACE THE BATTERY WITH ANOTHER CR2032-TYPE BATTERY.

2 SETTING THE PARAMETERS

General information:
Allowed settings:
• Km/h (kilometres per hour) or M/h (Miles per hour)
• Wheel size (rolling circumference) [mm]
• Clock format: 12-hour / 24-hour
• Current date
• Maintenance
TO ENTER THE PARAMETER SETTINGS MODE HOLD DOWN THE RIGHT AND LEFT
BUTTONS FOR APPROX. 3s.
THE WORD "Unit" WILL FLASH ON THE DISPLAY.
The operational logic is structured as follows:
• The instrument enters SETUP mode displaying the parameters according to the
sequence listed above.
• The instrument displays the parameter to be changed for a few seconds in flash
mode.
• If you wish to change the parameter displayed for those few seconds simply
edit the values by pressing the right and/or left buttons (according to the modes
listed below), otherwise wait a few seconds (approx. 5 s) to proceed to the next
parameter.
• When the parameter has been edited to the desired value, the instrument au-
tomatically moves onto the next setting, there is no need to press any button of
confirmation.
• If you only wish to enter the setup mode to view the configured settings, simply wait
without pressing any buttons; the instrument will display all of the set parameters
and will then automatically go back to "Normal Mode".
symbol appears when the battery is
