CHECK OF STEERING PLAY
Periodically check the play in the steering
sleeve by moving the fork back and forth
as shown in the figure. Whenever you feel
play, adjust as described below:
- Loosen the screws 1
2
40Nm
- Loosen nut 2
- Reduce the play by turning ring 3
3
Tighten the bolts to the prescribed torque
values.
1
20Nm
