Technical Data - Carl Valentin DUOPRINT Kurzanleitung

Technical Data

Print resolution
Max. print speed
Print width
Passage width
Printhead
Labels
Labels, continuous rolls
Max. material weight
Min. label width
Min. label height
Max. label height
Max. roll diameter
Core diameter
Winding
Label sensor
Transfer ribbon
Ink
Max. roll diameter
Core diameter
Max. ribbon length
Max. width
Dimensions in mm
Width x height x depth
Weight
Dimensions in mm with optional external unwinder
Width x height x depth
Weight
Electronics
Processor
RAM
Slot
Battery cache
Warning signal
Interfaces
Serial
Parallel
USB
Ethernet
Operation data
Power supply
Power consumption
Nominal Current
Fuse values
Operating temperature
Max. humidity
DuoPrint 107/12
305 dpi
150 mm/s
106.6 mm
116 mm
Corner Type
paper, cardboard, textile, synthetics
220 gr/m² (larger on demand)
15 mm
25 mm
1200 mm / 1100 mm (option)
(larger on demand)
External unwinder: 300 mm
External rewinder: 300 mm (option)
40 mm / 75 mm (option)
outside or inside
transmission or reflexion from bottom
outside or inside
Ø 90 mm
25.4 mm / 1"
450 m
110 mm
275 x 380 x 475
ca. 22 kg
275 x 410 x 825
ca. 24,5 kg
High Speed 32 Bit
16 MB / 64 MB (on demand)
for Compact Flash card Type I
for Real-Time clock (storage of data with shut-down)
acoustic signal when error
RS-232C (up to 115200 Baud)
Centronics (SPP)
2.0 High Speed Slave
10/100 Base T, LPD, RawIP-Printing, DHCP, HTTP, FTP
110 ... 230 V / 50 ... 60 Hz
600 VA
230 V - 1.5 A / 110 V - 3 A
230 V - 3.15 A / 110 V - 5 A
5 ... 35 °C
80% (non-condensing)
English
DuoPrint 160/12
305 dpi
120 mm/s
160 mm
176 mm
Corner Type
50 mm
25 mm
800 mm / 700 mm (option)
(larger on demand)
40 mm / 75 mm (option)
outside or inside
outside or inside
Ø 90 mm
25.4 mm / 1"
450 m
170 mm
335 x 380 x 475
ca. 27 kg
335 x 410 x 825
ca. 29,8 kg
DuoPrint
97
