c) Inspecting the Control Functions

After switching on the transmitter and connecting the rechargeable battery to the model's speed controller,
your model is ready for operation. The motor should not start up or hum in this moment.
Check the rudder linkage. Move the steering wheel for steering (figure 6, item 1).
Steering to the left must cause the rudder (viewed from behind in driving direction) to swivel to the left as well. If this
is not the case, you need to select the steering servo reverse function at the transmitter (see operating instructions
of the remote control).
If the steering wheel for the steering function at the transmitter as well as the trimming for it are in the neutral position,
the rudder must be placed centrally. Otherwise, the trimming at the transmitter must be adjusted accordingly (see
operating instructions of the remote control). Alternatively, or if transmitter trimming is no longer sufficient, you need
to readjust the linkage with the control wheel in the neutral position and neutral trimming by loosening the screws at
the linkage levers (figure 3, item 3).
"Metal / metal" screw connections must be secured against unintended loosening either with so-called "stop
nuts" or with a drop of thread locker varnish.
Check the function "driving forwards". The throttle lever of the transmitter (figure 6, item 2) permits smooth adjustment
of the model's driving speed. The farther you push the lever to the handle, the faster must the ship's propeller turn and
the faster will the ship move forward.
If the motor only starts up when the throttle lever is pushed forward, you need to activate the "Reverse" switch at the
transmitter for the driving function. For this, observe the operating instructions of the remote control system.
The speed controller can also be programmed for "reverse driving" (see chapter 11). This function is not
recommended for the model, however, since the model ship will submerge at the rear here. The flood chan-
nel would fill with even more water, and increase the resulting slant of the model. This will cause water to
splash over the rear part of the boat deck, so that it may run into the boat.
Figure 6
