8.

Preparations

The model ship "Mini Mono" is delivered almost ready for operation. Only a few steps are required for com-
missioning.
Before completing the model or taking it into operation, read each section carefully. The stages are almost
always illustrated for better understanding.

a) Boat Rack Assembly

The scope of delivery includes a boat rack of plastic that has to be assembled and glued together first.
Build the boat rack of the four plastic parts as shown in figure 1. The side parts (figure 1, item 1) must be built so that
the wide side points down. The side parts are attached into the long parts (figure 1, item 2). Glue the plastic parts on
with a drop of viscous instant adhesive or some 5-minute epoxy glue.
Place the model boat on this boat stand for further inspections or for the later preparation for operation.
Figure 1
33
