• Connect the mains cable low-voltage plug to the connection POWER IN (9) at the device.
• Plug the mains plug of the mains line into a grounded socket.
• Once the device is connected to the mains, it is ready for operation.
• It is switched on and off with the mains switch (11).
• Other similar effect beamers can also be connected to the mains via the POWER OUT (10) connection. For this,
plug a mains extension (available in specialist stores) into the connection POWER OUT (10) and connect it to the
connection POWER IN (9) of the next device.

11. Operation

a) Setting the Operating Mode
The effect light can be controlled with the integrated controller or with an external DMX controller. Additionally, it can
be used as a master device with integrated controller to control other connected effect lights synchronously in master-
slave mode, or as slave device via the controller of another effect light.
After switching on (putting the mains switch (11) in the ON position), the light effect will perform a reset.
Only after this process is completed will the device be ready.
• Use the display (3) and MENU (4) and ENTER (7) buttons as well as the UP (6) and DOWN (5) buttons to set the
operating mode.
• Press the MENU (4) button to select the individual menu items.
• Push the button ENTER (7).
• Change the values to be set or options with the UP (6) or DOWN (5) buttons.
• Confirm the selection with the ENTER (7) button.
• To go back one level in the menu without changes, push the MENU (4) button once.
• To return to the display of the current operating mode, push the MENU (4) button for one second or wait for approx.
10 seconds.
