English
Transmission frequency
The minimum network variable transmission interval can be set by describing
the nciMinOutTm configuration input with a valid clock.
Preset service type: unacknowledged
Energy consumption
network output SNVT_elec_kwh nvoEnergyConsum
This optional output network variable provides the energy consumption of the
pump or, in the case of double pumps, the total energy consumption of the
master and slave. The counter is reset to 0 kWh after 65535 kWh.
Value range
0 – 65535 kWh (in 1 kWh steps).
Transmission
This value is transmitted whenever a change is made.
Transmission frequency
The minimum network variable transmission interval can be set by describing
the nciMinOutTm configuration input with a valid clock.
Preset service type: unacknowledged
Control mode for normal operation
network input config SNVT_dev_c_mode nciControlMode
This optional input network variable defines the control mode for normal operation
of the pump if no external sensors are used and no overriding settings are active.
Value range
Value
DCM_SPEED_CONST
DCM_PRESS_CONST
DCM_PRESS_COMP
DCM_PRESS_AUTO
Default value
DCM_PRESS_COMP
SCPT reference: SCPTdeviceControlMode (238)
58
Function
Constant speed mode
Constant pressure mode
Compensated pressure mode
Temperature-dependent differential pressure
