Input- Mand. NVT
Networkvariable Opt.
nviRequest M SNVT_obj_request
nviPumpSetpoint M SNVT_switch
nviPumpOpMode M SNVT_hvac_mode
nviPumpOvdStop O SNVT_switch
nviOvdSpeed O SNVT_lev_percent
nviOvdPress O SNVT_press
nviRemotePress O SNVT_press
nviRemoteTemp O SNVT_temp_p
Object No. Receive Data Range
Heartbeat and Units
0 1 no -
1 1 no .state: 0 – 1
.value: 0.0
- 100.0%
1 2 no enum 0 ... 17
(hvac_t)
1 6 no .state: 0 – 1
.value: 0.0
... +100.0%
1 7 no -163.84
... +163.83 %
1 8 no -3276.8
... +3276.6 kPa
1 10 yes -3276.8
... +3276.6 kPa
1 12 yes -273.17
... +327.66 °C
Resolution Default Value Invalid Data
- - -
- SCPTsetpoint -
- HVAC_AUTO 0xFF
(HVAC_NUL)
- .state: 0xFF .state: 0xFF
.value: 0xFF
0.005 % 0x7FFF 0x7FFF
0.1 kPa 0x7FFF 0x7FFF
0.1 kPa 0x7FFF 0x7FFF
0.01°C 0x7FFF 0x7FFF
Data Range and
effective
resolution WILO
.object_id: 0 - 1
.object_request:
RQ_NORMAL
RQ_DISABLED
RQ_ENABLE
RQ_UPDATE_STATUS
RQ_REPORT_MASK
RQ_CLEAR_STATUS
.state: 0 – 1
.value: 0.0 – 100.0%
HVAC_AUTO
HVAC_MRNG_WRMUP
HVAC_PRE_COOL
HVAC_ECONOMY
.state: 0 – 1
.value: 0.0 – 100.0%
0 - 100%
Eff. Resolution: 0.5%
Range depends on
Pumptype.
Eff. Resol.: 0.981kPa
0–3276.6kPa
Eff. Resol.: 0.981kPa
-273.1 – 327.6 °C
Eff. Resol.: 0.1°C
