Before placing the Hydro Insert in storage, you
should remove all pellets from the hopper with
a vacuum cleaner with a long extension. If the
fuel is left in the hopper, it may get damp, stick
together, and be difficult to light at the beginning
of the next season. If pressing the main switch
(located on the back of the Hydro Insert) does not
make the control panel display light up, it could
mean that the service fuse needs replacing. On
the rear of the Hydro Insert there is a fuse holding
compartment which is located underneath the
supply socket. With a screwdriver open the cover
of the fuse holding compartment, and re place the
fuse if necessary (3,15 AT delayed type). Plug the
unit back in and press the main switch.
CLEANING BY THE TECHNICAL
Check every year
Compartment ventilation flue gas cleaning
Remove the fixing screws and remove the smoke
fan for cleaning of the same. Perform the task with
the greatest care not to bend the fan blades.
Exchanger cleaning
Remove the combustion chamber plate to
1
remove it, push the plate upwards and then rotate
it towards the front.
1a
1c
40
1b
Clean the pipes behind
the plate.
Extract the chimney insert using the
2
appropriate handles and remove the
protective casing.
2a
2c
Remove the insulation,
clean the exchanger and
scrape the pipes where
the fumes pass.
Clean flue
Clean the flue system especially near the fittings
to "T", curves and any horizontal sections. Is
necessary to check and remove any deposit of ash
and soot before the same clogging the passage of
smoke.
2b
