It is mandatory to have an opening in the brick /
plasterboard coating to guarantee an adequate
supply of air to the chimney (see page 8).
It is recommended to replicate the same opening
made on the perimeter wall. Alternatively, the
suction pipe (Ø 50 mm) can be connected to
the outside of the home. If the suction tube
is taken only outside of the brick cladding,
it is mandatory to have an air intake on the
perimeter wall of the house.

Remote Control

The remote control (Fig. 3) used to adjust water
temperature power and the on/off functions for
the pellet Hydro Insert.
To start the Hydro Insert, press key
Insert will automatically enter the starting phase.
Press keys + (1) and - (2) to adjust temperature,
and use keys + (6) and - (5) to adjust operating
power.
To turn off the Hydro Insert, hold down key .
To replace the 3 volt battery located on the back
of the remote control, pull the centre of the cover
and the lever on the side of the same, replace the
battery observing the correct polarity (Fig. 4)
and the Hydro
Remember that it is forbidden to
inhale the combustion air from
bedrooms, bathrooms, garages or
deposits that could have explosive
atmospheres.
Fig. 3 Fig. 4
11
