1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability
for damage to the product or caused by the product
arising from:
• Improper handling
• Failure to comply with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE 0113 not being observed
Note:
The operating manual is part of this product. It includes
important instructions for the safe, proper and econom-
ic operation of the product, for avoiding danger, for min-
imising repair costs and downtimes and for increasing
the reliability and extending the service life of the prod-
uct. In addition to the safety instructions in this operat-
ing manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specified areas of ap-
plication. Keep the operating manual in a good place
and hand over all documents when passing the product
on to third parties.
2. Product description
1. Drum
2. Mixing unit
3. On/off switch
4. Engine unit
4a Screws
5. Transport wheels
24 | GB
6. Machine stand
7. Swivel wheel
8. Foot
9. Drum upper section
10. Drum lower section
11. Frame middle section
12. Foot with wheel axle
13. Locking disc
13a Holder
14. Bearing support
3. Scope of delivery
Item
2
4
5
7
8
9
10
11
12
13
14
15
16
17
18
19
4. Proper use
The concrete mixer can be used for home work to mix
concrete and mortar. The concrete mixer is only intend-
ed for private use in the home and garden.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or inju-
ries of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, as well as the assembly in-
structions and operating information in the operating
manual.
www.scheppach.com
Quantity Designation
2x Mixing unit
1x Engine unit
2x Transport wheels
1x Swivel wheel
1x Foot
1x Drum upper section
1x Drum lower section
1x Frame middle section
1x Foot with wheel axle
1x Locking disc
1x Bearing support
1x Locking plate
1x Actuating rod
1x Extension rod
8x Enclosed accessories bag
1x Operating manual
