• Keep hands and feet away from the moving parts.
• Do not reach into the mixing drum while it is running.
• Do not put any objects into the mixing drum while it
is running, e.g. shovel or similar.
• Danger of injury when the mixing drum is rotating.
• The concrete mixer may only be operated with orig-
inal spare parts.
• Repairs to the concrete mixer may only be carried
out by authorised specialist companies.
• Do not leave ready-to-use concrete mixer unattended.
• Switch off the machine and pull out the mains plug
when leaving the workstation.
Residual risks
The machine has been built according to the state-
of-the-art and the recognised technical safety re-
quirements. However, individual residual risks can
arise during operation.
• Danger of injury due to rotating parts.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Before performing setting or maintenance work,
switch the motor off and unplug the mains plug.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "Safety In-
structions" and the "Intended Use" together with the
operating manual as a whole are observed.
• Avoid accidental start-ups of the machine: Make
sure that the ON/OFF switch is set to "0" before in-
serting the plug into the socket.
• Use the tool that is recommended in this operating
manual. This is how to ensure that your machine
provides optimum performance.
• Keep your hands away from the working area when
the machine is in operation.
Warning! This power tool generates an electromagnet-
ic field during operation. This field can impair active or
passive medical implants under certain circumstances.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the power tool.
6. Technical data
Motor
Engine output
Max. speed:
Max. drum speed:
Capacity
Diameter of drum
opening
Insulation class:
Dimensions
Operating mode:
Protection class
Weight
Subject to technical changes!
*S6 30 %: Continuous duty with intermittent loading
(operating time 10 min.)
In order avoid impermissible overheating of the motor,
the motor should be driven for only 30% of the operat-
ing time with the stipulated nominal power and must
then continue to run with no load for the remaining 70%
of the operating time.
Information about noise development
Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Noise data
The noise levels have been determined in accordance
with EN ISO 3744:2010.
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
Guaranteed sound power level L
www.scheppach.com
MIX125
230 V~ / 50 Hz
0.55 kW
2750 rpm
26.6 rpm
125 l
385 mm
IP45D
1200 x 710 x
1400 mm
S6 30%
II
45 kg
pA
pA
WA
WA
WA
MIX140
230 V~ /
50 Hz
0.55 kW
2750 rpm
26.6 rpm
140 l
385 mm
IP45D
1200 x 710 x
1400 mm
S6 30%
II
47 kg
72.21 dB
3.33 dB
92.21 dB
3.33 dB
95 dB
