Scheppach DP3000 Originalbetriebsanleitung Seite 30

Electrical residual risks
Electrical contact
Touching the spark plug may cause an electrical shock.
– Never touch the spark plug while the engine is running.
Thermal residual risks
burns, chilblains
Touching of the exhaust/ case may cause burns.
– allow motor driven machines to cool.
Danger from noise
hearing damage
Prelonged unprotected work with the device may
cause hearing damage.
– Always wear ear-muffs
Danger caused by materials and other substances
Contact, inhalation
The emissions of the machine may cause damages
to health.
– Only use the motor driven machine outdoors.
Fire, explosion
m Fuel is flammable.
– During work and refuelling smoking and open
flames are prohibited.
In case of emergency
In case of a possibly occuring accident take the nec-
essary first aid steps as appropriate and obtain qual-
ified medical aid as quickly as possible.
If you obtain aid please give the following informa-
tions:
1. Where did it happen
2. What happened
3. How many injured
4. Type of injury
5. Who is reporting!
7. Technical data
Engine
Transmission
Load capacity
Box length
Box width
Box Depth
Weight
Engine Type
Idle speed
maximum RPM
Motor Starters
30 | GB
4.1 kW
3F+1R
300 kg
910 mm
650 mm
575 mm
143 kg
4-stroke engine
1800 1/rpm.
3600 1/rpm.
Recoil starter
www.scheppach.com
Unleaded fuel octane number
Fuel
90 and max. ethanol of 5%
Fuel tank capacity
Required engine oil
Gear oil
Max. slope
Max. oil tank
capacity
Subject to technical modifications!
Noise
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Information concerning noise emission meas-
ured according to relevant standards:
Sound pressure L
pA
Sound power L
wA
Uncertainty K
pA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration Steering Lever A
hv
Uncertainty K
PA
The specified vibration emission value has been
measured according to a standardised testing proce-
dure and can be used for comparison of one electric
tool with another. The specified vibration emission
value can also be used for an initial assessment of
the load
m WARNING
The vibration emission value can vary from the spec-
ified value during the actual use of the electric tool,
depending on the type and the manner in which the
electric tool is used. Try to minimise stress from
vibrations as low as possible. Some examples of
means for reducing the vibration stress are wearing
gloves while using the tool and limiting work time. In
the process all parts of the operating cycle must be
taken into account (such as times in which the elec-
tric tool is switched off or time in which it is switched
on, but is not running under a load).
Limit the noise and vibration to a minimum!
8. Unpacking
Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available)
Check that the delivery is complete.
3.6 l
SAE 10W-30
SAE30 / 80W-90
20°
0.6 l
84,7 dB
95,0 dB
3,0 dB
3,92 m/s
2
1,5 m/s
2
