PIN FUNCTION
24
RS485-B
EXTERNAL ALARM
25
COM
All manuals and user guides at all-guides.com
Under the normal operation, COM disconnects with NO. But when any alarm is
triggered, COM connects with NO.
Attention: The voltage restriction is under DC24V 1A.
73
APPENDIX 6 PIN CONFIGURATION
DESCRIPTION
