Index Subindex
Name
Switching Signal Channel .2
62
1
SSC.2 Param SP 1
62
2
SSC.2 Param SP 2
63
1
SSC.2 Config Logic
63
2
SSC.2 Config Mode
63
3
SSC.2 Config Hystere-
sis
14.1.3.4
Teach
Index Subindex
Name
Teach Single Value
58
1
Teach Select
2
–
System Command -
Teach SP1
2
–
System Command -
Teach SP2
Data type
Access rights
Value range Description
Uint32
R/W
-60 ... 20
Uint32
R/W
-60 ... 20
Uint8
R/W
Uint8
R/W
Uint32
R/W
20 .. 0
Data type
Access rights
Value range Description
UInt8
R/W
UInt8
W
UInt8
W
Setpoint 1 of SSC.2.
Setpoint 2 of SSC.2.
Selects the logic of SSC.2.
0: High active
n
1: Low active
n
Selects the switching behavior of SSC.2.
0: Deactivated
n
1: Single point
n
2: Window
n
3: Two point
n
The hysteresis width of SSC.2.
Selects the switching signal channel for which a teach procedure
will be applied.
1 = SSC.1
n
2 = SSC.2
n
Teach SP1
65 = Teach SP1
n
Teach SP2
66 = Teach SP2
n
