Thank you for choosing a Peg Perego
product.
Product characteristics
• Suitable for children between 40 and 87 cm with a
maximum weight of 13 kg.
• This is a Universal Belted Enhanced Child Restraint System.
It is approved according to UN Regulation No. 129/03 for
use primarily in Universal seating positions, as indicated by
vehicle manufacturers in the vehicle user's manual.
• The use of the car seat for premature infants born at less
than 37 weeks could cause respiration problems for the
newborn. It is advisable to seek medical advice before
leaving the hospital.
• This car seat is approved for installation in the car without
the base or with the Base i-Size/Base Twist/Base Giro.
• When used with a Base i-Size/Base Twist/Base Giro, this car
seat becomes an "i-Size" enhanced child restraint system. It
is approved in accordance with UN Regulation No. 129/03
for use in i-Size-compatible vehicle seating positions, as
indicated by vehicle manufacturers in the vehicle users'
manual.
• The car seat can only be used in approved vehicles, fitted
with static or inertia-reel three-point seatbelts, approved
under regulation UN/ECE no. 16 or equivalent standards. It
must not be used with two-point or lap seatbelts.
• Consult the list of car models and seats equipped with
ISOFIX anchor systems (see inside) that have been approved
by the restraining system manufacturer.
Contact the restraining device manufacturer or retailer if you
have doubts or require further information on the fitting of
the Base i-Size/Base Twist/Base Giro in specific cars.
For more information, please contact the Peg Perego
Assistance Department at the address
customer.service@pegperego.com
• This car seat comes with "Adjustable Side Impact
Protection": improved protection against side impacts with
the "simultaneous system" for headrest-harness adjustment.
WARNING
• Read the instructions carefully before use and keep
them in the holder provided for future reference. Failure
to closely follow the car seat installation instructions
will put your child at risk.
• The assembly and installation operations must be
conducted by adults.
• Always use a car seat when in the car. Never remove the
child from the car seat when the vehicle is in motion.
• Never leave a child alone and unsupervised in a car,
not even for a short time. The temperature inside the
vehicle can change rapidly and become dangerous for
the child inside.
• Install this car seat facing the direction opposite to the
direction of travel.
• Install this car seat only on seats facing the direction of
travel. If the vehicle has rotating or repositionable seats,
position them facing the direction of travel.
• Do not fit this car seat onto passenger seats which have
active airbags. Deactivate the airbag before fitting the car
seat. Using this car seat on seats with active airbags may
cause serious injury or death in the event of an accident.
• Check that the child car seat is not blocked by a moving part
of the seat or a door.
• Scrupulously follow installation instructions; do not use
installation methods other than those recommended
because they could cause detachment of the car seat.
• Always use the harness when using this car seat.
• Adjust the height and tension of the shoulder straps
ensuring that they are snug to the child's body without
constricting him/her too much. Check that the harness is
not twisted and that the child does not release it.
• To avoid the risk of falling, always use the car seat harness
even for transport outside the vehicle.
• The car seat is not a substitute for a cot; if the child needs to
sleep it is important to lie him/her down.
• Do not use the child car seat if it is broken or if there are
missing parts, or if it has been subjected to heavy impacts
as a result of accidents, as it may have suffered structural
damage which is not visible but is extremely hazardous.
• Do not use the car seat without its fabric cover; this must
not be replaced with one not approved by the manufacturer
since it is an integral part of the car seat and the safety
system.
• Do not remove the white polystyrene part under the cover
and in the headrest as it is an integral part of the safety
devices.
• Do not leave the car seat in the vehicle when exposed to
the sun. Some parts might heat up and be harmful to the
delicate skin of the child - check before placing the child in
the seat.
• Do not modify the product.
• Do not remove the adhesive and stitched labels since
this might make the product non compliant with legal
requirements.
• For any repairs, replacement parts and information about
the product, contact the after-sales assistance service.
Contact information is provided on the last page of this
manual.
• Do not use accessories not approved by the manufacturer
or by the competent authorities.
• If using a second-hand product, make sure it is a recent
model, comes with instructions, and is fully functional
14
in all parts. An obsolete product may not conform to
safety standards, due to natural ageing of materials and
updating of regulations. If you have any doubts, contact the
manufacturer's customer service centre.
• Make sure there are no items of luggage or other unsecured
items in the vehicle interior. They could injure the vehicle's
occupants in the event of an accident.
• This product requires only minimal cleaning and
maintenance. These operations must be performed by
adults.
• It is advisable to keep all the moving parts clean.
• Clean plastic parts periodically with a damp cloth. Do not
use solvents or similar substances.
• Do not clean the polystyrene shock absorbing device with
solvents or other similar products.
• Brush fabric parts to remove dust. If you wash fabric parts,
follow the washing instructions on the laundry label.
• Protect the product from atmospheric agents: humidity, rain
or snow. Extended exposure to sunshine can cause colour
changes in many materials.
• Store the product in a dry environment.
WARNING: FOR USE AS A RECLINED
CRADLE.
• Do not use the reclined cradle once your child can sit
unaided.
• This reclined cradle is not intended for prolonged
periods of sleeping.
• It is dangerous to use this reclined cradle on an elevated
surface, e.g. a table.
Components of the Product
Inspect the content of the package and contact Customer
Care if any items are missing.
The child car seat includes:
a) Hood
b) Handlebar
c) Dual Stage Cushion
d) Headrest
e) Harness tension release button
f) Harness tension adjustment strap
g) 3-point safety harness with shoulder straps
h) Reclining lever
i) Headrest height adjustment button
l) Instruction manual compartment
m) Headrest lined with shock-absorbing expanded polystyrene
(EPS)
n) Shock-absorbing expanded polystyrene (EPS) inserts
o) Kinetic Pods: side protections.
p) Lever for release from base
q) Chest Clip
The car seat is ready for use: no assembly required.
How to install the car seat with the base
Primo Viaggio Lounge features the Ganciomatic System
for connection and release in the car with the Base
i-Size/Base Twist/Base Giro.
Refer to the user manual inside the box to install the
Base i-Size/Base Twist/Base Giro car seat bases.
1 To recline the backrest in the 3 positions available, use the
handlebar on the upper end of the backrest.
2 Attach the car seat to Base i-Size/Base Twist/Base Giro.
Release the car seat by pulling the lever on the lower end of
the backrest while lifting the car seat.
3 Press the two buttons on the handlebar, rotate it and
position it in the direction of the vehicle seat. Installation is
now complete.
4 The car seat handlebar has four fixed positions. To rotate it,
press the two buttons on the handlebar and move this to
the required angle. Ensure it clicks into position.
• Position A: the in-vehicle position;
• Position B: the position for transport by hand and for
installation on a base, stroller or chassis;
• Position C: this is the resting position;
• Position D: stops the car seat from rocking.
How to install the car seat without the
base
When used without base, you can install Primo Viaggio
Lounge with the BACKREST IN THE UPRIGHT POSITION,
ONLY.
5 If the backrest is reclined, use the handlebar on the upper
end of the backrest to bring it to the upright position.
IMPORTANT! The car seat must be parallel to the
ground. If necessary, you can place rolled-up towels or
swimming pool float tubes in the folds of the vehicle's seats,
as shown in the figure.
Fit the car seat with the child seated inside, remembering to
secure the child with the harness.
6 Slide the lower part of the vehicle seatbelt into the two
guides on the car seat (fig_a) and buckle it (fig_b), ensuring
the seatbelt is taut, as shown in the figure.
Grasp the upper part of the vehicle seatbelt and pass it
behind the car seat backrest (fig_c).
7 Insert the belt into the rear guide (fig_a). Tighten the vehicle
seat belt. Turn the handlebar against the vehicle seat. For
the handlebar functions, refer to fig_6 in this manual.
8 The seat is fitted with Kinetic Pods, to ensure greater safety
in the event of a side impact. Once you have positioned
the seat in the car, pull out COMPLETELY the Kinetic Pod
situated on the side FACING THE CAR DOOR by turning it
clockwise (fig_a). To return the Pod to its initial position,
