CONTROLLER LED REFERENCE
Event
Power on
Power off
Battery level check
Component pairing scan
Component pairing connected
Component pairing success
Component pairing failure
BLE connected
BLE disconnected
BLE bonds deleted
Controller low battery
Sensor low battery
Sensor not connected
Solenoid open
Solenoid fault
Calibration required
Calibration initiated
Calibration success
Calibration failure
Ready for firmware update
Firmware update in progress
System failure at startup
Green LEDs rotate around the circle clockwise, then counter-clockwise, then displays battery level
Red LEDs illuminate and then rotate counter-clockwise around the circle
After pressing the Power button quickly, LEDs display battery level (1/4=25%, 1/2=50%, etc.)
Solid green for duration of solenoid in open position
Two fast yellow every second, then a red every second
Blink Sequence
One medium green every half second
Solid green
Ten medium green
Ten medium red
Two medium blue
Three medium blue
Three medium cyan
Two quick red every five seconds
Three quick yellow every five seconds
One medium yellow every second
Single purple LED rotating around the circle
Solid green
Two purple
Two red
Solid purple
Solid blue
One red every minute
