11. EXPLANATION OF OPERATION OF THE
MECHANISM
11-1. Figure of Mechanism
The mechanism is shown in Fig. 11-1 and Fig. 11-2.
11-2. Explanation of Mechanism Mode
The mechanism has the 7 modes, namely @ EJECT,
@ UNLOADING, @ LOADING COMPLETION, @ FF,
© STOP, © PLAY, ® REVIEW.
The major operations of each mode are as follows:
(1) EJECT;
The cassette holder lock is released. if the holder lock is
released, it returns at once to the unloading position.
(2) UNLOADING;
The tape is unloaded. The mechanism is waiting for the
cassette tape to be set.
(3) LOADING COMPLETION;
The position where the cassette tape has been taken out from
the cassette and wound around the drum (usually, the
mechanism does not stop in this mode).
(4) FF;
FF/REW operation is performed in this mode. The reel deck
drive is set to FF state, and the reel deck brake is released.
(5) STOP;
The tape travel is stopped. The brake is depressed to the reel
deck.
me "i ek
ING
0 @
HS ce
jy)
ee
LOADING
COMPLE-
umMso [sys
ums1 [1 yo
ums2 fo fi fo
0: Shorting toCOM
1: Open to COM
a
MOVING
RX-P1H RX-P1H
(6) PLAY;
The tape is sent at constant speed. The pinch roller is
depressed, the capstan rotates, and constant back tension is
given to the tape.
(7) REVIEW;
The tape is sent back with constant speed. The pinch roller is
depressed to the capstan, the capstan rotates inversely, and
the back tension brake is depressed to the take-up reel deck.
The changing of mechanism mode is transmitted to the specific
lever through the cam by the drive motor. In this case the
position in specific mode is detected by the detection switch.
The mode change state and modes of detection switch are
shown below.
EJECT—>UNLOADING-—(LOADING COMPLETION)
—FF>STOP#sPLAY->PEVIEW
The direction of the arrow (->) indicates the direction of unwinding
the tape, and the drive motor runs counterclockwise (CCW).
ia STOP |MOVING| PLAY | MOVING] REVIEW
® ® @
Cae a | a es
lo Hive, =
jo
0
0
1
ae
Table 11-1 Table of detection switch modes
~71-
LOADING
MOTOR ASS' Y
CAPSTAN MOTOR ASS' Y
DRUM
var
OS
CASSETTE
POST (LEFT)
EXIT POLE
ENTRANCE POLE BASE ASS' Y
BASE ASS' Y
SUPPLY REEL
Figure 11-1 Top side of mechanism
PINCH POLLER
COUPLER LEVER
PINCH ROLLER LEVER
EXIT LINK
LEVER ASS' Y
PINCH ROLLER
OPERATION
GEAR ASSS' Y
CASSETTE
POST{(RIGHT )
PINCH ROLLER
TAKE-UP REEL
CAPSTAN MOTOR ASS' ¥
|
'MODE DERECTI ON
SWITCH
DRIVE. BELT
i ESSN
OPERAT ION
WEVELR
DRIVE PULLEY [J
BOTTOM REEL 1
BOTTOM REEL
CSUPPLY SIDED
CTAKE-UP SIDE)
SF ee
REDUCT ION
GEAR
BRAKE LEVERCL)
COUPLER GEAR
PLAY GEAR ASS' Y
BRAKE LEVERCR)
SLIP GEAR ASS' Y
Figure 11-2 Bottom side of mechanism
