Endress+Hauser Proline Prosonic Flow 93 C Betriebsanleitung Seite 22

Montage
22
Prosonic Flow C
Nennweite
[mm] [inch]
700 28"
– 30"
800 32"
900 36"
1000 40"
– 42"
1200 48"
– 54"
– 60"
– 66"
1800 72"
– 78"
Prosonic Flow C
Nennweite
[mm] [inch]
300 12"
350 14"
400 16"
– 18"
500 20"
600 24"
AWWA Druckstufe Schrauben
Class D 28 × 1 1/4 "
Class D 28 × 1 1/4 "
Class D 28 × 1 1/4 "
Class D 32 × 1 1/2 "
Class D 36 × 1 1/2 "
Class D 36 × 1 1/2 "
Class D 44 × 1 1/2 "
Class D 44 × 1 3/4 "
Class D 52 × 1 3/4 "
Class D 52 × 1 3/4 "
Class D 60 × 1 3/4 "
Class D 64 × 2"
ANSI Druckstufe Schrauben
[Ibs]
Class 150 12 × 7/8 "
Class 150 12 × 1 "
Class 150 16 × 1"
Class 150 16 × 1 1/8 "
Class 150 20 × 1 1/8 "
Class 150 20 × 1 1/4 "
Proline Prosonic Flow 93C PROFIBUS PA
Max. Anziehdrehmoment
[Nm]
247
287
394
419
420
528
552
730
758
946
975
853
Max. Anziehdrehmoment
[Nm]
133
135
128
204
183
268
Endress+Hauser
[lbf ft]
182
212
291
309
310
389
407
538
559
698
719
629
[lbf ft]
98
100
94
150
135
198
