Indoor unit installation
• Pay attention to the following points when the indoor unit is
installed in a hospital or other facilities where there are elec-
tromagnetic waves from medical equipment, etc.
- Do not install the indoor unit where the electromagnetic
wave is directly radiated to the electrical control box, re-
mote control cable or remote control switch.
- Install the indoor unit and components as far as practical or
at least 3 meters from the electromagnetic wave radiator.
16.3 INSTALLATION
The dimensions of the suspension bracket (accessory) and the unit installation are indicated in following figures.
RPK-(0.6-1.0)FSN(H)3M
  
26
Min.
Left side of
100
service space
Suspension
bracket
45
22
Exterior contour for indoor unit
313
145
298
292
230
6 14 28 31
42 20 36 22 22 45
25 39 65
11
45 13
12
175
182
294
(*1)
Ø 65
Left rear side hole
for pipings and wirings
PMML0292A rev.2 - 09/2015 - P5416572
- Prepare a steel box and install the remote control switch in
it. Prepare a steel conduit tube and wire the remote control
cable in it. Then, connect the ground wire with the box and
the tube.
Install a noise filter when the power supply emits harmful
-
noises.
• To avoid any corrosive action to the heat exchangers, do not
install the indoor unit in an acid or alkaline environment.
344
382
330
324
239
28 28 14
32 32 42 22 22 51
55 53 60 39 25
11
13 32
13
169
12
201
344
790
(*1)
Ø 65
Right rear side hole for
pipings and wirings
107
Min.
263
100
6
19 66
17
55
107
(*1): RPK-(0.6-1.0)FSNH3M
It is recommended to connect the
piping at the right rear side of the
body to avoid the sound from the
refrigerant running through.
Right side of
service space
