2.4.2 Installation example: recirculation mode

S
AFETY INSTRUCTIONS REGARDING THE INSTALLATION
When installing the appliance, ensure optimal heat radiation to maintain the
operating safety.
The wall and the reach of the heat radiation above the worktop must be made of
heat-resistant materials.
To avoid any damage, the sandwich layer and adhesive must resist heat.
Provide an installation opening relevant to the dimensions on the drawings in
chapter 2.3 S / D .
ELECTION OF THE INSTALLATION ENVIRONMENT IMENSIONS
For installation and use, a minimum of 50 mm space shall be preserved around
the installation opening.
The thickness of the worktop must be at least 30 mm. Choose heat-resistant
materials for the work top only to avoid any deformation caused by the heat-
radiation of the appliance.
The safety distance between the induction hob and a wall cupboard above must
be at least 760 mm.
S
COPE OF DELIVERY
The scope of delivery only includes the induction hob with an integrated extractor
fan (2), the extractor fan cover (15), the grease filter (16) and the curved (90°)
support tube (8). See fig. below « O :
VERVIEW INDUCTION HOB AND EXTRACTOR
».
FAN FOR USE IN RECIRCULATION MODE
The accessories required for extraction or recirculation mode are available
from specialised retailers.
~ ~
