The battery controller starts the visual display when the On/Off switch has been activated on the front (switch
light is on).
The row of LEDs (seven yellow LEDs, one red LED) indicates the current residual capacity. As the capacity
decreases, the yellow LEDs go out from right to left. When the residual capacity drops below the boundary
value "Warning time" (approx. 25 %), the last yellow LED flashes. When the final discharge limit is reached,
the red LED lights up and an acoustic signal sounds.
After a set time of approx. five minutes, all consumers on the cart apart from the acoustic signal are
automatically switched off. You can deactivate the acoustic signal with the On/Off switch.
NOTE
If the mobile workstation is discharged down to the final discharge limit, the battery must be fully
recharged in order to reset the battery controller. It is therefore urgently necessary to charge it for
5 till 10 hours or to insert a fully charged battery tray.
The battery controller takes a few seconds for the restart after the first time it is switched on after
deep discharging.
