20.1.1 Perforated grid

The MAX BE mobile workstation has a perforated grid with the dimensions 10 mm x 10 mm and a spacing of
38 mm on the rear panel and on the lower battery cover. Various holders or similar items can be hung
variably here.
Figure 11: Perforated grid of the MAX BE
20.1.2

Information on installed parts

20.1.2.1 Charger
The charger installed in this mobile workstation can be connected to any shockproof socket with a mains
voltage of 230 V AC – 50 Hz. If the battery tray is inserted and operating temperature has been reached,
charging starts immediately after connection to the mains.
We recommend fusing the socket with a 16 A automatic circuit breaker with a C characteristic.
NOTE
Never allow the mobile workstations' batteries to discharge to below the end-point voltage,
specifically not below 19 V.
A deep discharge protection feature is integrated in the mobile workstation which prevents this
deep discharging under normal operating conditions. The batteries should be recharged soon
after switching off by the deep discharge protection function to prevent further deep discharging
through self-discharging.
The Mobile Workstation with Li-ion batteries should be charged at least every four weeks.
If the mobile workstation is not used for more than 4 weeks, fully charge it and disconnect the
battery plug. To restart the Mobile Workstation, follow the steps in Chapter 16 Initial set-up.
Charger mains cable
For better accessibility, you can attach the mains cable for the internal charger to the top post on the right.
Alternatively, store it behind the rear panel.
