Cushion for therapy tray table
Assembly
The therapy table padding is velcroed directly onto the
therapy tray table� (Fig� 23)

7.2.5. Head

Head rest
The MAGICLIGHT head rest is selected as standard
®
from the ALULINE range�
Assembly
The ALULINE universal holder is mounted to the back
rest using the screws supplied�
Adjustment
The height of the head rest can be adjusted using the
lower clamping lever on the universal holder (Fig� 24)�
Depending on the model, the inclination and/or depth
of the head rest can be adjusted using the clamping
lever on the ratchet�
Important!
Always release only one clamping lever
and make the adjustment here� Only
continue with the next one after the previous one
has been secured�
Important!
The gap between head rest cushion and
back rest cushion must not be more
than 60 mm!
Fig 23
Fig 24
SETTINGS / OPERATION
41
