Fronius DeviceNet Robacta CTC Bedienungsanleitung Seite 43

Input
(From the fieldbus
coupler to the stan-
dard I/O 2 connecting
plug)
E16
Output signals for Robacta Reamer V 70 Han12P:
Output
(From the standard
I/O 2 connecting plug
to the fieldbus coup-
ler)
+24 V
GND
A09
A10
A11
A12
A13
A14
A15
A16
Input signals for Robacta Reamer V Comfort:
Input
(From the fieldbus
coupler to the stan-
dard I/O 2 connecting
plug)
E09
E10
E11
E12
E13
E14
E15
E16
Output signals for Robacta Reamer V Comfort:
Pin on the Signal
standard I/O 2
connecting
plug
18 Reserve
Pin on the Signal
standard I/O 2
connecting
plug
1 -
2 -
3 Start cleaning
4 Inject parting agent
5 Cut the wire electrode
6 GND for sensors
7 Reserve
8 Reserve
9 Reserve
10 Reserve
Pin on the Signal
standard I/O 2
connecting
plug
11 Gas nozzle free
12 Sensor output signal
13 Sensor output signal
14 Parting agent level OK
15 Reserve
16 Cleaning motor top
17 Reserve
18 Reserve
Action
-
Action
-
-
High
High
High
High
-
-
-
-
Action
High
High
High
-
-
High
-
-
43
