Connections and connector pin assignments

Connections for
robot controls to
Robacta FB
8I_8O (Robacta
CTC)
Connections to Robacta FB 8I_8O
Connections for
robot controls on
the outside of Ro-
bacta TX, TX 10i,
TX/i TWIN
34
(1)
(1) Perforated plate with rubber bu-
shings
(2) Standard I/O 1 connecting plug
for connection with Robacta CTC
(3) Supply connection socket +24 V
AIDA
for supplying the bus coupler and
the field bus terminals
(2)
(3)
(1) Perforated plate with rubber bu-
shings
(2) Supply connection socket +24 V
(1)
AIDA
for supplying the bus coupler and
the field bus terminals
(2)
