Output
(From the standard
I/O 2 connecting plug
to the fieldbus coup-
ler)
A14
A15
A16
Input signals for Robacta Reamer V:
Input
(From the fieldbus
coupler to the stan-
dard I/O 2 connecting
plug)
E09
E10
E11
E12
E13
E14
E15
E16
Output signals for Robacta Reamer V:
Output
(From the standard
I/O 2 connecting plug
to the fieldbus coup-
ler)
+24 V
GND
A09
A10
A11
A12
A13
A14
A15
A16
Input signals for Robacta Reamer V Twin:
Pin on the Signal
standard I/O 2
connecting
plug
8 Reserve
9 Reserve
10 Reserve
Pin on the Signal
standard I/O 2
connecting
plug
11 Gas nozzle free
12 Gas nozzle clamped
13 Cleaning motor turns
14 Parting agent level OK
15 Cleaning motor bottom
16 Cleaning motor top
17 Wire cutter open
18 Wire cutter closed
Pin on the Signal
standard I/O 2
connecting
plug
1 -
2 -
3 Clamp gas nozzle/cleaning
motor on
4 Inject parting agent
5 Cut the wire electrode
6 Cleaning motor up
7 Optional GND for sensors
8 Reserve
9 Reserve
10 Reserve
Action
-
-
-
Action
High
High
High
High
High
High
High
High
Action
-
-
High
High
High
High
High
-
-
-
