Dimensions

3.8

Scope of delivery

Fig. 10: Scope of delivery
3.9

Accessories

Installation and operating instructions • RAIN3 • Ed.04/2023-10
Fig. 9: Main views with main dimensions
L
Length
W
Depth
H
Height
A
Discharge port G 1" ◁
Rainwater storage tank connection G 1" ◁
B
Tap water connection G 3/4" ◀
642 x 260 x 715 mm ("L×W×H")
Scope of delivery for Wilo-RAIN3:
System
Pioneering for You
Fill level sensor (level sensor)
Wilo-RAIN3
Fixation material (frame wall plugs)
Installation and operating instructions
de Einbau- und Betriebsanleitung
nl Inbouw- en bedieningsvoorschriften
Quick Start Guide
en Installation and operating instructions
el Οδηγίες εγκατάστασης και λειτουργίας
fr
Notice de montage et de mise en service
cs Návod k montáži a obsluze
·
"Not drinking water" and "Protect from frost" stickers
4232897 • Ed.02/2020-02
Pioneering for You
Wilo-RAIN3
QUICK
START
de Quick Start Guide
en Quick Start Guide
fr Quick Start Guide
nl Quick Start Guide
4263496 • Ed.01 / 2023-05
https://qr.wilo.com/536
Floating extractor:
Fine suction filter (type F = without non-return valve, type FR = with non-return valve)
52
G3/4"
B
A
75
B
G3/4"
G1"
G1"
L
en
52
49
