5. Carefully remove the hexagonal bolt which at-
taches the hexagonal shaft to the frame of the
snowblower and gently knock on the end of the
shaft to loosen the ball bearing from the right side
of the frame. Take care to not damage the thread
of the shaft.
6. Remove the other ball bearing from the left side of
the frame by removing the spring washer.
7. Carefully pull out the hexagonal shaft downwards
and to the left before pulling the friction wheel
drive from the shaft.
Feed screw clutch and drive clutch (Fig. 15)
If the clutch lever of the feed screw or drive clutch are
disengaged and in the disengaged position, the cable
should have very little slack. It should be taut.
The feed screw must stop within 5 seconds when the
clutch lever of the feed screw is disengaged. If the feed
screw clutch cannot not activated or deactivated prop-
erly, adjust the feed screw clutch before operating.
If the snowblower drive periodically deactivates or
moves during operation when the drive clutch lever
disengages, adjust the drive clutch before operation.
Both the feed screw clutch and the drive clutch can be
adjusted at both ends of their control cable.
1. Loosen the adjusting nuts (c) on the bowden cable
holder (d).
2. Slide the control cable up or down by screwing
the adjusting nut in order to increase the cable
tension or provide more slack.
3. Screw the adjusting nut (c) to slide the cable down
or up so that the cable tension increases or pro-
vides more slack.
4. Tighten the nuts after the corresponding adjust-
ments have been carried out.
Please provide the following information in the
event of any enquiries:
• Machine data - type plate
• Engine data - type plate
Important note in the case of repairs:
For return delivery of the device for repair, please en-
sure for safety reasons that it is free of oil and fuel
when it is sent to the service centre.
Service information
With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
Wearing parts*: Sweeping brushes, belt drives, en-
gine oil, spark plug, air filter, rubber lip, collecting box,
snow plate wear strip, wheels
* may not be included in the scope of delivery!
Spare parts and accessories can be obtained from
our Service Centre. To do this, scan the QR code on
the front page.
14. Disposal and recycling
Notes for packaging
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
electrical devices.
Fuels and oils
• Before disposing of the unit, the fuel tank and the
engine oil tank must be emptied!
• Fuel and motor oil do not belong in household
waste or drains, but must be collected or disposed
of separately!
• Empty oil and fuel tanks must be disposed of in an
environmentally friendly manner.
www.scheppach.com
The packaging materials are
recyclable. Please dispose of
packaging in an environmen-
tally friendly manner.
