4.7 Opening with override key – aluminium control unit
If, for example no code is available, the lock can be opened by means of the override key.
To expose the keyhole, the bar handle has to be removed (see diagram 5).
Figure 1:
Diagram 5: Dismantling the bar handle, horizontal mounting

4.7.1 Opening

1) Insert the Allen key (2 mm) provided into the rear hole (see fi gure 1)
Loosen the screw inside from the shaft mounting, but do not completely unscrew it
2)
(see fi gure 3)
3) Pull out the bar handle with the drive shaft (square end) (see fi gure 2)
If the shaft mounting (see fi gure 3) covers the keyhole, pull out Allen key. Adjust the
4)
shaft mounting with the aid of the drive shaft (square end) so as to reveal the keyhole
5) Insert key and turn clockwise until stop position reached (key cannot be removed)
If the code needs to be changed, proceed as follows. A penalty time activated has to
elapse before a new primary code can be programmed in.
6) Press ON
7) Press P
8) Press P
9) Press 0
10) Press ON
11) Press P
12) Enter new 6-digit primary code
13) Enter new 6-digit primary code once again
14) Insert key and turn anti clockwise until stop position reached
Kaba Mauer GmbH
Figure 2:
82132 Code-Combi B
Figure 3:
Shaft mounting
1 x
