4.6 Opening with override key – plastic control unit
If, for example no code is available, the lock can be opened with the override key. To expose
the keyhole the cover plate on the control unit has to be removed with a suitable tool.
The removal of the control unit will be recognised by the lock as attempted sabotage. This
dismantling will be signalled on every subsequent operation after entering the code. The
signal has to be cancelled (see 4.5.2).
Tool
Diagram 4: Cover fi tting, horizontal construction

4.6.1 Opening

1) Press tool into the right hand hole until the catch loosens
2) Hold the tool pressed in and carefully raise the cover plate
3) Repeat the process on the left hand hole
4) Now carefully lift off the cover plate
5) Remove bar handle and drive shaft (square end)
6) Replace cover plate (without bar handle) and engage
Insert key and turn clockwise until stop position reached
7)
(key cannot be removed)
If the code needs to be changed, proceed as follows. A penalty time has to elapse be-
fore a new primary code can be programmed in.
8) Press ON
9) Press P
10) Press P
11) Press 0
12) Press ON
13) Press P
14) Enter new 6-digit primary code
15) Enter new 6-digit primary code again
Kaba Mauer GmbH
Cover plate
Lift here
82132 Code-Combi B
GB
/
/
1 x
1 x
