16.2

Order numbers

Grounding kit
The ground connection must be installed in the immediate
vicinity of the solar power inverter. We recommend using
the "Grounding Set A Solar" grounding kit from Delta.
Grounding kit
Grounding Set A Solar
Cable couplings
Cable coupling types for the DC connections to the inverter.
The DC+ connection of the solar power inverter is a plug,
the DC– connection is a socket.
DC connection Cable coupling type
DC+ Socket
DC– Plug
MultiContact UTE kit
The Multi-Contact UTE Kit is designed to conform to the
latest French standard UTE C 15-712-1. It contains 8 DC
measuring elements, a mounting tool and an additional
signal-flash drive. This kit allow you to conform to the DC
protection and signal requirements specified in UTE C
15-712-1.
Multi-contact UTE kit
Multi-contact UTE kit for SOLIVIA EU Solar Inverter
RS485 cable
RS485 connection cable
Cable for connecting solar power inverters
Push/Pull cable from Harting, IP67, one side with a blue manager, the other side with a white cable manager
1,5 m
3,0 m
5,0 m
10,0 m
20,0 m
Connecting cable from the last solar power inverter to a monitoring gateway device, e.g. Solivia Basic
Gateway, Solarlog or Meteocontrol WEB'logger
Outdoor cable, IP65, with Harting RJ45 PushPull and RJ12 plugs
If you wish to install cables yourself in order to connect
inverters to each other then you must use cable managers
from Harting (IP67 PushPull system cable RJ45).
We recommend using a blue cable manager on one side
and a white cable manager on the other side.
Cable manager
RJI IP67 data plug Push Pull 8-pin white
RJI IP67 data plug Push Pull 8-pin blue
HARTING Deutschland GmbH & Co. KG (PF 2451,
D-32381 Minden, www.harting.com)
Operation and installation manual for SOLIVIA 11 EU G4 TR
Conductor cross-section
mm AWG
2
1,5 / 2,5 14
4 / 6 10
1,5 / 2,5 14
4 / 6 10
Cable sheath diameter
mm
3–6
5,5–9
3–6
5,5–9
3–6
5,5–9
3–6
5,5–9
Appendix
EN
Delta part number
EOE990000275
Order number
32.0010P0001-UR
32.0012P0001-UR
32.0014P0001-UR
32.0016P0001-UR
32.0011P0001-UR
32.0013P0001-UR
32.0015P0001-UR
32.0017P0001-UR
Delta part number
EOE90000341
Delta part number
3081186300
3081186500
3081186600
3081186200
3081186400
Contact Delta support
Harting part number
09 45 145 1500
09 45 145 1510
