10.2.6 RS485 (EIA485)

Description
Menu:
150 RS485
Menu access:
Main menu > Install settings > RS485
Example display:
03 1 5 0 R S 4 8 5
- - - - - - - - -
I D :
➔
B a u d r a t e :

Configurable parameters

Display text Designation
ID RS485 ID
Baud rate Baud rate
Termination: Termination resis-
tor
NOTE
Connecting multiple solar inverters via
RS485
► Select a different ID for each solar
power inverter.
► Set the termination resistor to On at the
last solar power inverter in the row.
10.3

Grid freed-in settings

Description
Menu: 470 Feed-in settings
Menu access:
Main menu > Production info> Feed-in
settings
Example display:
03 4 7 0 F e e d - i n s e t t i n g s
- - - - - - - - -
C u r r e n c y :
➔
E U R / k W h :
Configurable parameters
Display text Designation
Currency Currency
EUR / kWh EUR / kWh
Operation and installation manual for SOLIVIA 11 EU G4 TR
- - - - - - - - - -
1
1 9 2 0 0
Description
1 .. 255
2400 | 4800 | 9600 | 19200
| 38400, the standard is
19200
On | Off
- - - - - - - - - -
E U R
0 . 2 8
Description
No pre-defined values.
No pre-defined values. The
amount (EUR) per kWh is
required for the turnover
calculation.
10.4

Active and reactive power control

NOTE
This chapter applies only to LVD or MVD
grids. The 500 User settings menu is not
displayed for all other grids.

10.4.1 Overview

The 500 User settings menu provides various functions for
configuring the active and reactive power control.
Function/Mode Availability
LVD
Effective power control
Power reduction x
Power/Frequency x
Reactive power control
Constant cos φ x
cos φ (P) x
Reactive power con-
stants
Q (U)
Fault Ride-Through
(FRT)
10. Settings
Description
MVD
x For setting the maximum
generated active power
x For setting the power
gradient with respect to
the frequency
x For setting a fixed value
for cos φ (inductive or
capacitive)
x For setting a value of cos
φ (inductive or capacitive)
depending on the active
power ratio P/P
n
x For setting the reactive
power ratio Q/S .
n
x For setting the reactive
power ratio Q/S depend-
n
ing on the voltage V.
x For setting the feed-in cur-
rent in the case of a sym-
metric failure (= 3 phase)
or asymmetric failure
(= 2 phases).
EN
39
