NOTE
► If you set a power limit then you
must also fill out the label stating
"The power of the product has been
reduced ..." and apply this label to
the front of the solar power inverter.
Use a waterproof pen for filling out
this information.
10. Select Continue and press the E
L o c k e d p o w e r l i m i t
- - - - - - - - - - - - - - - - - - -
P m a x : 1 1 . 5 k W
➔
S m a x : 1 2 . 0 k V A
→ The Format menu is displayed.
11. Define the date and time formats.
F o r m a t
- - - - - - - - - - - - - - - - - - -
D a t e : D D . M M . Y Y Y Y
➔
T i m e :
Configurable parameters
Display text Designation
Date Date format
Time Time format
12. Select Continue and press the E
F o r m a t
T i m e :
C o n t i n u e
➔
- - - - - - - - - - - - - - - - - - -
→ The Date and time menu is displayed.
13. Set the date and time.
D a t e a n d t i m e
- - - - - - - - - - - - - - - - - - -
D a t e : 1 2 . 0 3 . 2 0 1 2
➔
T i m e : 1 0 : 1 4 : 2 3
14. Select Continue and press the E
D a t e a n d t i m e
T i m e : 1 0 : 1 4 : 2 3
C o n t i n u e
➔
- - - - - - - - - - - - - - - - - - -
→ The RS485 menu is displayed.
15. Set the RS485 ID and the baud rate.
R S 4 8 5
- - - - - - - - - - - - - - - - - - -
I D :
➔
B a u d r a t e : 1 9 2 0 0
Operation and installation manual for SOLIVIA 11 EU G4 TR
button.
ntEr
1 2 h
Description
DD.MM.YYYY
DD/MM/YYYY
DD-MM-YYYY
MM.DD.YYYY
MM/DD/YYYY
MM-DD-YYYY
YYYY.MM.DD
YYYY/MM/DD
YYYY-MM-DD
12h | 24h
button.
ntEr
2 4 h
button.
ntEr
1
Configurable parameters
Display text Designation
RS485 ID
ID
Baudrate Baud rate
Termination: Termination resis-
tor
NOTE
Connecting multiple solar inverters
via RS485
► If multiple solar power inverters are
to be connected via RS485, select
a different ID for each inverter. This
ID will also be used later to identify
each solar power inverter when
loading settings or transferring data.
► Set the termination resistor to "ON"
at the last solar power inverter in
the row.
16. Select Continue and press the E
R S 4 8 5
T e r m i n a t i o n :
C o n t i n u e
➔
- - - - - - - - - - - - - - - - - - -
→ The last menu is displayed.
E N T E R
t o c o n f i r m
E S C
t o s e l e c t a g a i n
17. Press the E button to finish commissioning.
ntEr
þ
Commissioning is now finished.
8. Commissioning
Description
1 .. 255
2400 | 4800 | 9600 |
19200 | 38400, the
standard is 19200
ON | OFF
button.
ntEr
O f f
