12. Diagnostic and maintenance
NOTE
The following displays are example only.
The actual autotest results may be different.
03 6 1 1 A T R e p o r t 1
R e s u l t : F A I L
1 2 . 1 0 . 2 0 1 1 0 9 : 2 3 : 3 5
I T F W
03 6 1 1 A T R e p o r t 1
L 1 O V T : P A S S
S e t : 2 6 2 V < 0 . 1 0 s
T e s t : 2 2 0 V < 0 . 0 8 s
03 6 1 1 A T R e p o r t 1
L 1 U V T : F A I L
S e t : 1 8 6 V < 0 . 2 0 s
T e s t : 2 2 0 V < 0 . 1 8 s
03 6 1 1 A T R e p o r t 1
L 1 H F T : P A S S
S e t : 5 0 . 3 0 H z < 0 . 1 0 s
T e s t : 5 0 . 0 1 H z < 0 . 0 8 s
03 6 1 1 A T R e p o r t 1
L 1 L F T : P A S S
S e t : 4 9 . 7 0 H z < 0 . 1 0 s
T e s t : 5 0 . 0 1 H z < 0 . 0 8 s
The results for phases L2 and L3 are shown in the same manner.
Menu:
600 Diagnostic&Alarm
Menu access:
Main menu > Diagnostic&Alarm > IT
Autotest
Example display:
03 6 0 0 D i a g n o s t i c & A l a r m
I T A u t o t e s t
➔
I n t e r n a l l o g
12.9

Maintenance

DANGER
Danger from hazardous voltage
Hazardous voltage is applied to the solar
power inverter during operation. Hazardous
voltage is still present 5 minutes after all
power sources have been disconnected.
► Never open the solar power inverter.
The solar power inverter contains no
components that are to be maintained
or repaired by the operator or installer.
Opening the cover will void the war-
ranty.
Ensure that the solar power inverter is not covered during
operation.
Regularly clean the solar power inverter to prevent soiling of
the housing.
