EP5/6PTS HRX
Fig. 8 Optional accessories
EP 5PTS15 HRX10 - AT, EP 6PTS28 HRX10 - AT, EP 5PTS15 HRX10 - RE, EP 6PTS28 HRX10 - RE
205 204
Fig. 9 Optional accessories
206
Double ended bits – type D12
203 202 201
200
308 175
Atlas Copco Tools - No. 9836 1682 03
Ref. No. Ordering No.
200 (201-205) 4210 2776 90
201 4250 1686 00
202 –
203 0517 1153 00
204 –
205 0335 1115 00
g Replaces Ref.No. 190 at applications with high feed forces
Ref. No. Ordering No.
For all models
206 4250 2423 00
Single ended bits and
double ended bits – type D14
308
Spare parts list
NB Qty Description
g 1 Bearing kit
1 Washer
1 Washer
23 Ball (2 mm)
1 Ring
1 Circlip (SgA 13)
NB Qty Description
1 Protective cover
175
