EP5/6PTS HRX
Fig. 2 Pulse unit
EP 5PTS13 HRX42 and EP 6PTS25 HRX42
= Included in O-ring Kit
= Included in Service Kit
210
215
214 213
212
B
205
204
203 202 201
200
OFF
2 Nm
2.5 mm
Ref. No.
Ordering No.
EP 5PTS13 HRX42
140 (141-205)
4250 1806 83
141
4250 1806 01
159
4250 1816 00
EP 6PTS25 HRX42
140
4250 1806 63
142
4250 1806 04
159
4250 1816 01
All models
143
4250 1814 00
144
4250 1800 00
145
0196 1552 66
147
4250 1759 00
148
4250 1760 00
150 (151,152)
4250 1813 80
151
–
152
4250 1853 00
154
–
157
0517 0102 02
158
4250 1869 00
160
4250 1815 00
161
4250 1863 00
162
–
(157)
180
211
185
184
183
175
167
168
165
OFF
50 Nm
No. : 4080 0819 80
NB Qty
Description
c
1
Pulse unit
(1/4" female hexagon,
quick change chuck)
1
Housing
1
Spring
c
1
Pulse unit
(1/4" female hexagon,
quick change chuck)
1
Housing
1
Spring (yellow)
1
Stop pin
1
Spring
1
Stop screw (S6SS5x5)
1
Pin
1
Washer
1
Inertia body
1
Inertia body
1
Stop screw
a,b 1
Lock ring
1
Pin (NRA2x9,8)
1
Spring guide
1
Adjustment screw
1
Screw
a,b 1
O-ring (27,1x1,6 Viton)
Atlas Copco Tools - No. 9836 1682 03
Silastic 732 RTV
(141, 142)
308
182
141
164
163
162
142
143 144 145 147 148
140
OFF
Secure with Loctite 242
Ref. No.
Ordering No.
163
164
165
167
168
175
180 (182-184)
182
183
184
185
200 (201-205)
201
202
203
204
205
210 (211-215)
211
212
213
214
215
Accessories Included
306
308
a Including in Service Kit – 4081 0252 90
b Including in O-ring Kit – 4250 2058 90
c Oil included
Setting of tightening torque,
see fig. No. 10
OFF
3 Nm
306
Secure with Loctite 242
152 151
6 Nm
Secure with Loctite 242
2.5 mm
NB Qty
Description
4250 1808 00
1
Cam shaft
0517 1106 00
1
Ball (4 mm)
4250 1818 00
1
Washer
4250 1809 01
2
Piston
4250 1810 01
2
Roller
4250 1817 00
1
Anvil
4250 1812 90
1
Screw ring, compl.
–
a,b 1
O-ring
–
1
Screw ring
–
a,b 2
O-ring (2,6x1 Viton)
0211 1102 00
2
Screw (MC6S3x4)
4210 2776 90
1
Bearing kit
4250 1686 00
1
Washer
–
1
Washer
0517 1153 00
23 Ball (2 mm)
–
1
Ring
0335 1115 00
1
Circlip (SgA 13)
4250 1770 91
1
Quick change chuck
0517 1103 00
1
Ball (1/8")
–
1
Sleeve
–
1
Spring
–
1
Washer
0335 3512 04
1
Circlip (RW12)
4080 0823 00
1
Adjustment key
0106 8152 00
1
Pin (RPE 2x12)
Spare parts list
+
–
161
160
159
158
157
C
150
154
23
