Spare parts list
Fig. 5 Auto Trim valve AT-versions
51
52
53
54
62
59
58
50
60
61
63
65
71
64
66
67
68
= Included in
Service Kit
26
72
Open
69
OFF
70
Atlas Copco Tools - No. 9836 1682 03
Ref. No.
Ordering No.
50 (51-71)
4250 1878 90
51
52
4250 1878 02
53
4250 1881 00
54
58
4250 2181 00
59
4250 2308 00
60
4250 2177 00
61
4250 2180 00
62
4250 2132 00
63
0663 2109 51
64
4250 2175 80
65
4250 2178 00
66
0335 2125 00
67
0663 2118 00
68
4250 2179 00
69
4250 2313 00
70
4250 2222 00
71
0108 1691 21
Optional accessory
72
4080 1151 80
a Including in Service Kit – 4081 0252 90
k To be placed between tool handle and Auto Trim valve when checking
function of valve
Close
1.5 mm
max.
0.2 Nm
EP5/6PTS HRX
NB Qty
Description
1
Auto Trim valve, compl.
–
a
1
O-ring (12.37x 2.62)
1
Casing
1
Wire netting
–
a
1
Filter
1
Nut
1
Cover
1
Valve
1
Support ring
1
Spring
1
O-ring (1.6x1.3)
1
Throttle valve
1
Bracket
1
Circlip (SgH 23)
1
O-ring (11.3x2.4)
1
Cover
1
Seal washer
1
Plug
1
Spring pin
k
1
Sight glass
