EP5/6PTS HRX-RE
Fig. 13
Setting of tightening torque - RE-versions
–
+
Torque level
Accuracy
Min. 3-5 pulses
Max. 3 seconds
–
+
+
–
3 mm
Torque level
Accuracy
Min. 3-5 pulses
Max. 3 seconds
Start
Set the tigh-
tening torque
Check the
tightening
on your
actual joint
Trim valve
Not OK
(inside)
Reduce / adjust
the free speed
Check the
tightening
on your
actual joint
Not OK
Atlas Copco Tools - No. 9836 1682 03
–
+
OK
Fully opened = max speed
= 75 % of max speed
ca 6 turns
OK
Technical Instructions
Put the machine
in operation
Put the machine
in operation
31
