Spare parts list
Fig. 3 Pulse unit
EP 5PTS15 HRX10 and EP 6PTS28 HRX10
OFF
2 Nm
2.5 mm
190
193
192
191
A
185
184
180
= Included in O-ring Kit
= Included in Service Kit
Ref. No.
Ordering No.
EP 5PTS15 HRX10
140 (141-193)
4250 1806 82
141
4250 1806 01
159
4250 1816 00
EP 6PTS30 HRX10
140 (142-193)
4250 1806 64
142
4250 1806 04
159
4250 1816 01
All models
143
4250 1814 00
144
4250 1800 00
145
0196 1552 66
147
4250 1759 00
148
4250 1760 00
150 (151,152)
4250 1813 80
151
–
152
4250 1853 00
154
–
157
0517 0102 02
158
4250 1869 00
160
4250 1815 00
24
OFF
50 Nm
No. : 4080 0819 80
170
173
172
171
183
182
167
168
165
NB Qty
Description
c
1
Pulse unit
(3/8" square drive)
1
Housing
1
Spring
c
1
Pulse unit
(3/8" square drive)
1
Housing
1
Spring (yellow)
1
Stop pin
1
Spring
1
Stop screw (S6SS5x5)
1
Pin
1
Washer
1
Inertia body
1
Inertia body
1
Stop screw
a,b 1
Lock ring
1
Pin (NRA2x9,8)
1
Spring guide
1
Adjustment screw
Atlas Copco Tools - No. 9836 1682 03
Setting of tightening torque,
OFF
3 Nm
see fig. No. 10
Secure with Loctite 243
(157)
Silastic 732 RTV
141
(141, 142)
164
163
162
142 143 144 145 147 148
140
OFF
2.5 mm
Secure with Loctite 243
Ref. No.
Ordering No.
161
162
163
164
165
167
168
170 (171-173)
171
172
173
180 (182-184)
182
183
184
185
190 (191-193)
191
192
193
Accessory Included
306
a Including in Service Kit – 4081 0252 90
b Including in O-ring Kit – 4250 2058 90
c Oil included
306
152 151
150
6 Nm
NB Qty
Description
4250 1863 00
1
Screw
–
a,b 1
O-ring (27,1x1,6 Viton)
4250 1808 00
1
Cam shaft
0517 1106 00
1
Ball (4 mm)
4250 1818 00
1
Washer
4250 1809 01
2
Piston
4250 1810 01
2
Roller
4250 1807 90
1
Anvil, compl.
–
1
Anvil
4250 1948 00
1
Retainer pin
4250 1949 00
1
Spring
4250 1812 90
1
Screw ring, compl.
–
a,b 1
O-ring
–
1
Screw ring
–
a,b 2
O-ring (2,6x1 Viton)
0211 1102 00
2
Screw (MC6S3x4)
4210 2873 90
1
Bearing kit
4250 1686 00
1
Washer
–
1
Ring
0335 1115 00
1
Circlip (SgA 13)
4080 0823 00
1
Adjustment key
EP5/6PTS HRX
+
–
161
160
159
158
157
C
154
