1.6 R
EFERENCE DOCUMENTS
The instructions for use provided with each generator are
made up of a collection of documents of which this manual
represents the General Part. The following documents are
normally provided separate.
a EC declaration of conformity.
b Instruction manual for use and maintenance of the
generators,
(this manual).
c Engine use and maintenance manual.
mase
d List of Service Centres.
mase
e Warranty certificate.
f Warranty card.
1.7 R
EFERENCE REGULATIONS AND LEGISLATIVE PROVISIONS
mase
All generators are designed and manufactured in
compliance with the legislation in force.
The generator and its components are constructed in
accordance with the following applicable regulations and
directives.
2006/42/EC: and subsequent amendments:
Essential machine requirements for safety and health
protection ("Machine" directive).
2014/35/UE: Guarantee of safety of electrical material
intended for use within certain voltage limits, ("Low
Voltage" Directives).
2000/14/EC and 2005/88/EC Directive about noise
emission in environment (only for models indicated in
noise emission tab.) and national law who transposed it.
1.8 M
ARKING
The generator identification plate carries all the
identification data in accordance with the provisions for
EC marking for those cases where required. Below is a
facsimile of the identification plate fixed on the hull of
each generator.
1.9 I
DENTIFICATION OF THE GENERATOR UNIT
1 - Machine name
2 - Machine code
3 - Serial number
4 - Rated power
5 - Declared frequency
6 - Rated power factor
7 - Rated voltage
8 - Rated current
9 - Degree of protection
10 - Class of isolation
11 - Temperature max. of use
12 - Altitude max. of use
13 - Performance class
14 - Year of construction
15 - Manufacturer - Adress
16 - Weight
The machine code number, the serial number
and the year of construction must always be
indicated when contacting the manufacturer for
information, order of spare parts, etc..
1
2
Code
4
Rated power 3F
5
declared frequency
6
Rated power factor
7
Rated voltage
8
Rated current
9
Degrees of protection
10
Class of insulation
11
Temp. max of use
12
Altitude max. of use
13
Performance class
14
year of manifacture
MPF 16-22
3
Serial n°
KVA
Hz
Cos.
Ø
V V
A A
IP
15
°C
m
16
Mass Kg
GB
GB
