7.1

SETTING THE SPRING FORCE

CAREFUL

The spring force is set at the optimum setting in the
factory.

As a first measure slightly tighten the joint cover
(by a ¼ turn); this to achieve greater stability of the
luminaire head, if necessary
Otherwise:

Remove the service cover of the spring-balanced arm
(loosen the 2 Phillips screws)

Place a suitable tool (e.g. a 3 mm Allen key) into the hole
1, turn by ¼ turn in the direction of the arrow and repeat
until the desired stability is achieved

Screw the service cover on again (attention: do not
tighten too tight)
8.

DEMOUNTING

DANGER
Danger to life through an electric shock.
Before dismantling the luminaire, disconnect all pins from
the power supply.
DANGER
Injury hazard
The spring balanced arm is under a high spring force. If the
terminal device is not in the uppermost spring balanced
arm position, the spring balanced arm will move rapidly
upward and cause severe injury. Only dismantle the
terminal device when the spring balanced arm is in the
uppermost position
1
8.1

Disposal

Do not discard the luminaire with household waste.
Follow local regulations and bring the luminaire to
a disposal site or give it to a dealer with appropriate
service.
Cut the cable directly at the casing.
The products listed above are over 95% recyclable.
For a high percentage of the used materials to be
either physically reused or used for energy after the
end of this product's life cycle, the luminaires have
been designed with recycling in mind. They do not
contain materials that are hazardous or require
monitoring.
9.

ACCESSORIES


Ergonomic handle (order no. D10.442.000)

Handle cover (order no. D15.445.000)

10. ADDITIONAL INFORMATION

The luminaire itself is maintenance free.
Additional documents may
manufacturer for this product.
Using this luminaire does not pose a risk to other equipment.
To save energy, the luminaire should be switched on only
when it is actually needed.
Any serious incident that has occurred with the product must
be reported to the manufacturer or their representative
and the responsible authorities of the country in which
the user is located.
The radiation emitted by this product conforms to the
exposure limit value for reducing the risk of photo-biological
hazards based on IEC 62471.
ENG
be requested from the
