ENG

11. TROUBLESHOOTING

Fault
The luminaire does not light up
The luminaire does not light up
The luminaire does not light up

12. TECHNICAL DATA

Electrical data:
Rated input voltage
Frequency range
Power consumption
Integral electronic transformer
Photometric values per luminaire head:
Central illuminance Ec at a distance of 1.0 m
Light field diameter d10 at a distance of 1.0 m:
Triango 100
Triango Fokus 100
Light field diameter d50 at a distance of 1.0 m:
Color temperature:
Triango 100-1 colored
Triango 100-3 colored
Color rendering index Ra
Color rendering index R9:
Triango 100-1 colored
Triango 100-3 colored
Depth of illumination L1 + L2
Total irradiance Ee:
Relationship between irradiance Ee and illumination intensity Ec:
Remaining irradiance:
26
Possible cause
Contact fault
Lamp defective
No power supply
Troubleshooting
Switch on again
Contact manufacturer's
service department
Check voltage, check all
connections
100 – 240 VAC
50 / 60 Hz
140 – 185 VA
24 VDC output
100,000 lx **
dia. = 18 cm *
dia. = 18 cm / 23 cm / 28 cm*
Dia. = 10 cm *
4300K *
3700K*/ 4300K*/ 4700K*
≥ 95*
90*
95*
80.4 cm *
415 W/m
3.51 mW/m
1 shade: 27.9%
2 shades 0°: 63.4%
2 shades 45°: 48.5%
2 shades 90°: 25.3%
2 shades 135°: 62.3%
Tube: 100%
Tube + 1 shade: 28.2%
Tube + 2 shades 0°: 62.6%
Tube + 2 shades 45°: 49.1%
Tube + 2 shades 90°: 25.2%
Tube + 2 shades 135°: 60.5%
* -10% / +20% tolerance
** only for 4300K / D10 = 180mm
User profile
All
Only by manufacturer's
service department
Professional electrician
2
2
/lx
