Anziehdrehmomente Promag P für ANSI
Nennweite
Druckstufe
[mm] [inch]
15 ½"
15 ½"
25 1"
25 1"
40 1 ½"
40 1 ½"
50 2"
50 2"
80 3"
80 3"
100 4"
100 4"
150 6"
150 6"
200 8"
250 10"
300 12"
350 14"
400 16"
450 18"
500 20"
600 24"
Anziehdrehmomente Promag P für JIS
Nennweite
Druckstufe
[mm]
15
15
25
25
32
32
40
40
50
50
65
65
80
80
100
100
125
125
ANSI Schrauben
[lbs]
Class 150 4 × 1/2"
Class 300 4 × 1/2"
Class 150 4 × 1/2"
Class 300 4 × 5/8"
Class 150 4 × 1/2"
Class 300 4 × 3/4"
Class 150 4 × 5/8"
Class 300 8 × 5/8"
Class 150 4 × 5/8"
Class 300 8 × 3/4"
Class 150 8 × 5/8"
Class 300 8 × 3/4"
Class 150 8 × 3/4"
Class 300 12 × 3/4"
Class 150 8 × 3/4"
Class 150 12 × 7/8"
Class 150 12 × 7/8"
Class 150 12 × 1"
Class 150 16 × 1"
Class 150 16 × 1 1/8"
Class 150 20 × 1 1/8"
Class 150 20 × 1 1/4"
JIS Schrauben
10K 4 × M 12
20K 4 × M 12
10K 4 × M 16
20K 4 × M 16
10K 4 × M 16
20K 4 × M 16
10K 4 × M 16
20K 4 × M 16
10K 4 × M 16
20K 8 × M 16
10K 4 × M 16
20K 8 × M 16
10K 8 × M 16
20K 8 × M 20
10K 8 × M 16
20K 8 × M 20
10K 8 × M 20
20K 8 × M 22
Max. Anziehdrehmoment
PTFE PFA
[Nm] [lbf · ft] [Nm]
6 4 –
6 4 –
11 8 10
14 10 12
24 18 21
34 25 31
47 35 44
23 17 22
79 58 67
47 35 42
56 41 50
67 49 59
106 78 86
73 54 67
143 105 109
135 100 –
178 131 –
260 192 –
246 181 –
371 274 –
341 252 –
477 352 –
Max. Anziehdrehmoment [Nm]
PTFE
16
16
32
32
38
38
41
41
54
27
74
37
38
57
47
75
80
121
Montage
[lbf · ft]
–
–
7
9
15
23
32
16
49
31
37
44
63
49
80
–
–
–
–
–
–
–
PFA
–
–
27
27
–
–
37
37
46
23
63
31
32
46
38
58
66
103
35
