Touchscreen display

3 Touchscreen display
The user can control the operation of the printer with the control panel, for example:
• Issuing, interrupting, continuing and canceling print jobs,
• Setting printing parameters, e.g. heat level of the printhead, print speed, interface configuration, language
and time of day (→ Configuration Manual),
• Control stand-alone operation with a memory module (→ Configuration Manual),
• Update the firmware (→ Configuration Manual).
Many functions and settings can also be controlled by software applications or by direct programming with a
computer using the printer's own commands. Programming Manual for → details.
Settings made on the touchscreen display make the basic settings of the label printer.
It is advantageous, whenever possible, to make adaptations to various print jobs in the software.
3.1

Start screen

After switching on
Figure 4 Start screen
The touchscreen display is operated directly by touch:
• To open a menu or select a menu item lightly touch the corresponding symbol.
To scroll in lists slide finger up or down on the display.
Symbol Function
Open the menu
Interrupt the print job
Continue the print job
Table 1 Symbols
Inactive symbols are shaded.
40
During printing
Symbol
In pause state
Function
Repeat the last printed label
Cancel all print jobs
Feed a blank label
After print job
