4 INTRODUCTION TO YOUR ARB FRIDGE

The key components of your ARB Fridge are identified below in Figures 1 to 4.
Figure 1 – Front of fridge
1
2
3
4
15
16
17
1. Lid
2. Cooling vent LH
3. Lid latch x 2
4. Front carry handle
5. Control panel
6. Padlock position
7. Rubber feet x 4
8. Socket for wireless transmitter
9. Hinge x 2
10. Rear carry handle
11. Cooling vent RH
5
5
6
7
8
Figure 3 – Interior cabinet
12. 100-240V AC power socket
13. 12/24V DC power socket
14. Compliance plate and serial number
15. Gas strut
16. Drain plug
17. LED cabinet light
18. Reversible basket
19. Secondary cooling cabinet
20. Primary cooling cabinet
21. Basket divider
Figure 2 – Rear of fridge
18
19
20
21
9
10
11
12
13
14
